Thermal insulation lift-sliding door

Product specification:

Window frame thickness: 125mm

Window sash thickness: 51.8mm

Thermal insulation strip length: 14.8mm

Glass thickness: 20mm to 30mm

Wind load resistance: 4.5kPa, force 8

Air tightness: 1.5m3/(m.h), level 6

Water tightness: 400Pa, level 4

Thermal insulation property: 2.8-3.1W/(m2.K), level 4, level 5

Sound insulation property: 32dB, level 4

Aluminum alloy profile wall thickness: 2.0mm

Aluminum alloy material: 6063 T5

Door and window standard: Aluminum Alloy Doors and Windows GB/T 8478


Excellent thermal insulation property

Adopt broken bridge aluminum alloy profile; adopt insulating glass;

Sealed with sliding rubber strip;

Reasonable structural design:

Adopt dual-rail and monorail sections suitable for different applications;

The angle of both ends of aluminum alloy profiles assembled in the door frame and the door leaf is 45 degrees, which ensures high strength and simple process;

High strength, large size of door leaf:

The profile has a large cross-section and the wall thickness conforms to international standards;

Adopt a full set of lifting and sliding hardware, which has strong load bearing capacity;

The actuator can multi-lockup;
