Frame-type glass curtain wall is the factory production of a root component (column, beam) and a piece of glass (component) to the site, the column with connectors installed on the main structure, and then install beams on the column, forming a curtain wall frame after the installation of fixed glass (component).According to the curtain wall form is divided into: bright frame glass curtain wall, hidden frame glass curtain wall, semi-hidden frame glass curtain wall.

  • FOB Price: US $0.5 - 9,999 / Piece
  • Min.Order Quantity: 100 Piece/Pieces
  • Supply Ability: 10000 Piece/Pieces per Month

Product Detail

Product Tags

Modular curtain wall, refers to;The load of the curtain wall itself and the load of the curtain wall are mainly borne by the frame.Curtain wall installation method has Yin frame installation and bright frame installation.

Curtain wall is the outer wall enclosure of the building, not bearing the load, hang up like curtain, reason calls again “curtain wall”, it is the light wall that contemporary large and tall building commonly USES to contain adornment effect.

It is composed of the panel and supporting structure system, which can have a certain displacement capacity relative to the main structure or has a certain deformation capacity of its own, and does not assume the role of the main structure.

Curtain wall is the use of a variety of strong, light, beautiful building materials to replace the traditional masonry or window wall combined with the external wall construction method, is surrounded in the periphery of the main structure to make the whole building to achieve beautiful, the use of functional sound and safe external wall construction method.

In short, it is to put the building on a beautiful coat.Curtain wall scope mainly includes the exterior wall of the building, daylighting roof (canopy) and awning.

Frame-type curtain wall is a building envelope that is intended to support only its own weight and withstand the effects of environmental forces such as wind. It is not intended to assist the structural integrity of the building.

Here the framing members, most often linear aluminum extrusions called mullions, were fabricated and attached individually to the building. Long vertical framing members would be attached first, and incremental horizontals would then be attached to the verticals. Finally, the cladding materials were installed into the framed grid, fixed in place, and the weather seal applied.

Structural glass curtain wall is constructed mainly on site with mullions and transoms supporting glass, spandrel panels, metal panels , connected piece by piece. Each mullion is usually supported by the floor or perimeter beams.
